Dual Die MOSFET
Package |
Outline Dimension Download |
|---|---|
TSOP-6 |
- N Channel
Part |
Configuration ⁄ Polarity |
VDS (V) |
VGS Max (V) |
RDS(on) (mΩ) Max @ VGS = |
ID (A) |
QG (nC) |
PD (W) |
Package |
Datasheet |
||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
10V |
5V |
4.5V |
2.5V |
1.8V |
|||||||||
SSS8205 |
Dual N |
18 |
± 10 |
- |
- |
25 |
45 |
- |
5 |
10.5 |
1.25 |
TSOP-6 |
|
SSS8206 |
Dual N |
16 |
± 10 |
- |
- |
20 |
35 |
- |
5.5 |
10.5 |
1.25 |
TSOP-6 |
|
